RT-OPKE16-300M95

Specification Value
Magnification 3.00 (x)
Image circle diameter 82.0 (mm)
4.2″ IMX411 17.79 x 13.34 (mm x mm)
Line 16k-3.5µm 19.10 (mm)
Line 12k-5.2µm 20.80 (mm)
Line 16k-5µm 27.31 (mm)
Working distance 111.5 (mm)
Focal length 116
f/N 4.2
Distortion < 0.01 (%)
Depth of field 0.10 (mm)
Resolution 4 (μm)
Iris control Manual
Focus control Manual
Mount M95x1 FD 10
Phase adjustment No
Length 470.0 (mm)
Outer diameter 100 (mm)
Mass 368 (g)
Add to Quote
Category: Tag: Brand:

Description

  1. Working distance: distance between the front end of the mechanics and the object. Working distance production range ±5 mm.
  2. FD stands for Flange Distance (in mm), defined as the distance from the mounting flange to the camera detector plane.
  3. Indicates the availability of an integrated camera phase adjustment feature.
  4. Measured from the front end of the mechanics to the camera flange.

Additional information

Lens mount

M95x1 FD 10
Mass

368 (g)
Optmag

3.00 (x)
Color
Operation power source
Accessory developer

Opto
Line 16k 5m

27.31 (mm)
Zoom ratio

3.00 (x)
Working distance

111.5 (mm)
Depth of field

0.10 (mm)
Phase adjustment

No
Length

470.0 (mm)
Resolution

4 (μm)
Image circle diameter

82.0 (mm)
Focal length

116
Distortion

< 0.01 (%)
F/n

4.2
Iris control

Manual
Focus control

Manual
Outer diameter

100 (mm)
Line 16k 3.5m

19.10 (mm)
Line 12k 5.2m

20.80 (mm)
4 2 imx411

17.79 x 13.34 (mm x mm)
Focal length (mm)

116
