L5047MG100E

Sensor	4K
Image Sensor	CMOS
Shutter	Global
Resolution	4096 × 2
Line Rate	29 kHz(After compression the line frequency is 58k）
Bit Depth	12
Mono/Color	Mono
Pixel Size	3.5 μm × 3.5 μm
Pixel	4096 × 2
S/N Ratio	39.6 db
Dynamic Range	65.5 db
Image Format	Mono8/10/12/10P/12P
Binning	Support
ROI	Support
X Flip	Support
Gain	1~32
Gamma	From 0 to 4, support LUT
Exposure Time	8 μS~100 mS
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
FPN	Support
User Setting	Support two sets of user-defined configurations
Image Buffer	64MB Image Cache, 64M Data Cache
Port	GigE
GPIO Interface	12-pin Hirose interface for external power supply and external triggering; 2 differential/single-ended inputs, 1 differential configurable input or output, 1 high-speed optocoupler single-ended input, 1 GPIO configurable input or output
Lens Mount	C-Mount
Power Supply	DC12-24V power supply
Power Consumption	4.2 W
Product Dimensions	29 mm × 44 mm × 57.5 mm (Not including rear case connector)
Net Weight	100 g
Storage Temperature	-30℃~+80℃
Operating Temperature	0℃~+50℃

Description

The resolution is 4K, the pixel size is 3.5?m, and the maximum line frequency can reach 29K
High dynamic range, good signal-to-noise ratio, and excellent image quality
Support a variety of image data format output
Support 2TDI
Support multiple ROI, FPN correction
Support Gamma, LUT, automatic black level and other ISP functions
Support software trigger/hardware trigger/free run and other trigger modes
Compatible with GigE Vision V2.0 protocol and GenICam standard
Support DC12-24V wide voltage power supply

Binning	Support
Bit depth	12
Dynamic range	65.5 db
Exposure time	8 us~100 mS
Fpn	Support
Gain	1~32
Gamma	From 0 to 4，support LUT
Gpio interface
Image buffer	64MB Image Cache，64M Data Cache
Image format	Mono8/10/12/10P/12P
Image sensor	CMOS
Lens mount	C-mount
Line-rate	29 kHz(After compression the line frequency is 58k）
Pixel	4096 x 2
Pixel size	3.5 um x 3.5 um
Port	GigE
Power consumption	4.2 W
Power supply	DC12-24V power supply
Resolution	4096 x 2
Roi	Support
Sensor	4K
Shutter	Global
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support two sets of user-defined configurations
X flip	Support
Mono-color	Mono
S/n ratio	39.6 db
