C03-CL-SDR-SDR-PoCL-FC-3M

C03-CL-SDR-SDR-PoCL-FC-3M

Model C03-CL-SDR-SDR-PoCL-FC-3M
Category Camera Link data cable (SDR to SDR)
Appearance Color Black
Length 3m
End A Connector SDR26
End B Connector SDR26
Cable Structure 28AWG+ML+AL+B
Cable Diameter 9.5mm
Cable Sheath PVC
Connector Durability ?750 cycles
Min Bending Radius 100mm
Applicable Scenes Dynamic scenes
Number of Cycles Rubber Tracks Complete 10 million cycles
Packaging Method Individual package bag
Max Operating Voltage 30 VDC
Certifications RoHS2.0
Operating Temperature -20??80?
Add to Quote
Category: Tag: Brand:

Description

  • 1?Suitable for Camera Link industrial cameras
  • 2?SDR26 with screws, reliable connection camera
  • 3?With shielding layer design, to ensure anti-external electromagnetic interference
  • 4?With excellent flexibility, to meet the tank chain mobile installation applications
  • 5?Specific good wear resistance, cold resistance, flame retardant
  • 6?Conform to RoHS 2.0 & UL

Dimensions

Downloads

Additional information

Appearance color

Black
Applicable scenes

Dynamic scenes
Cable diameter

9.5mm
Cable sheath

PVC
Cable structure

28AWG+ML+AL+B
Certifications

RoHS2.0
Connector durability

≥750 cycles
End a connector

SDR26
End b connector

SDR26
Length

3m
Max operating voltage

30 VDC
Min bending radius

100mm
Packaging method

Individual package bag
Product category

Camera Link data cable (SDR to SDR)
